Basic Info.
| Parts no. | 1883065 | Material | Steel |
| Type | Pin | Part Type | Engineering machinery parts |
| Compatibility | Caterpillar | Transport Package | Wooden box |
| Trademark | DIRON | Origin | Luoyang City |
| HS Code | 84099991 | Production Capacity | 5000PCS/Year |
Product Details
- Date First Listed：2025/12/06
- Manufacturer：Diron Parts
Product Description
- Parts Type: Pin
- Escription: Replacement Parts Pin 1883065 Suitable for Caterpillar, New
The 188-3065 is a heavy-duty aftermarket boom-to-stick main pivot pin engineered for large Caterpillar® 70–90 ton hydraulic excavators. Forged from high-strength 40Cr alloy steel and deep induction-hardened across all bearing surfaces, this pin is designed to withstand extreme digging forces, massive shock loads, and continuous articulation in the toughest mining, quarrying, and mass-excavation environments.
Key Features & Benefits
- Forged 40Cr alloy steel with case hardness > HRC 57 (depth 12–15 mm)
- Thick hard-chrome plating option available for maximum wear and corrosion resistance
- Precision-ground diameters to ±0.02 mm tolerance for perfect bushing contact
- Spiral grease grooves + cross-drilled lubrication channels for easy maintenance
- Exceptional shear and bending strength – proven under maximum breakout and crowd forces
- Shot-blasted and finished with heavy-duty anti-corrosion coating
Common Applications (Caterpillar® Compatibility)
- Hydraulic Excavators – boom to stick (dipper arm) main pivot: – 365B, 365B L, 365C, 365C L – 374D, 374F – 385B, 385C, 385C L (some configurations)
- One of the highest-stress pins in the entire front linkage of these 70–90 ton class machines
- Frequently replaced during scheduled major linkage overhauls
Technical Specifications
- Part Number Reference: 188-3065
- Material: Forged & heat-treated alloy steel
- Outside Diameter: 149.98 mm (5.905 in)
- Overall Length: ≈ 650–680 mm (varies slightly by model)
- Weight: ≈ 165–180 kg (364–397 lb)
- Quantity per machine: 1
Important Note:
- We only provide replacement products intended for aftermarket use in the Caterpillar machinery listed above. The brand name Caterpillar is used solely as reference information to indicate compatibility and does not imply that our products are OEM.
- Note: While this description provides general information, specific details such as size, weight and exact material may vary by manufacturer and specific application. To obtain the most accurate and up-to-date information, it is recommended to consult a qualified parts supplier such as DIRON PARTS.
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We’ll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: FOB
Q4. How about your delivery time?
A: Generally, it will take 20 to 30 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q8. How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from
